Summary of Contents for Salus QUANTUM SQ610RF

  • Page 2: Table Of Contents

    4.3 Li-on battery charging....................................10 4.4 First power up sequence, language choice and preparing to pair process.....................10 5. Installation by SALUS Smart Home application (ONLINE MODE).........................11 5.1 General informations about SALUS Smart Home application........................11 5.2 Pairing with underfloor heating wiring centre (KL08RF/Control Box)......................12 5.3 Pairing with wireless TRV radiator head................................15...
  • Page 3 7. Installation in OFFLINE MODE without SALUS SmartHome application......................49 7.1 General informations....................................49 7.2 Pairing with underfloor heating wiring centre (KL08RF/Control Box)......................50 7.3 Pairing with wireless TRV radiator head................................51 7.4 Pairing with RX10RF receiver..................................52 8. OPERATING in OFFLINE MODE....................................53 8.1 Setpoint temperature change (manual mode).............................53 8.2 Schedule mode......................................54...

  • Page 5: Introduction

    TRV head, RX10RF boiler control module. In order to control SQ610RF over the Internet or via the SALUS Smart Home mobile app (ONLINE mode), it must be installed together with the UGE600 Internet gateway (sold separately). From the application level, it is possible to pair SQ610RF with other system elements, e.g. Smart Plug SPE600, Smart Relay SR600 or window/ door sensor OS600/SW600.

  • Page 6: Montage

    2. Montage: 2.1 Package Content: 1) SQ610RF Quantum thermostat 2) Wall mounting plate 3) Self-adhesive mounting tape 4) Mounting screws 5) Manual instruction 2.2 Proper thermostat location Please note: The ideal position to thermostat mounting is about 1,5m under floor level far from heating or cooling sources. Thermostat can’t be exposed to sunlight or any extreme conditions like for example draft.

  • Page 7: About Zigbee Network

    3. About ZigBee network 3.1 ZigBee network - creation and work ZigBee is a wireless network based on IEEE 802.15.4 standard and it’s communication takes place in the 2.4 GHz band. The network is based on a mesh topology, which allows for a very large range and high reliability. The maximum range of direct communication between two network nodes (devices) is about 100m in open space.

  • Page 8: Compatibility With Salus Devices (Online And Offline)

    3.2 Compatibility with SALUS devices (ONLINE AND OFFLINE) COMPATIBILTY WITH OTHER SALUS CONTROLS DEVICES ONLINE MODE OFFLINE MODE Universal Gateway is NOT Universal Gateway is CONNECTED TO THE INTERNET CONNECTED TO THE INTERNET You can use your devices locally You can configure and use all your without the SmartHome App.

  • Page 9: Before You Start (First Power Up)

    4. Before you start (first power up) 4.1 LCD icon Description 1. Menu/Settings description + Clock 11. Current Temperature / Setpoint Temperature 2. AM/PM 12. Holiday mode 3. Temperature unit 13. Temporary override mode 4. Heating indicator (icon is animating when there is heating demand) 14.

  • Page 10: Li-On Battery Charging

    Charging to full battery level may take up to 24h maximum. 4.4 First power up sequence, language choice and preparing to the pair process For more information scan this code or visit: www.salus-controls.com MENU / Press for 3 sec to POWER UP...

  • Page 11: Installation By Salus Smart Home Application (Online Mode)

    5.1 General Informations about SALUS Smart Home application Thanks to UGE600 Universal Gateway and SALUS Smart Home app system allows you to remote control of your heating system in any place you are in the moment by smartphone, tablet or computer with Internet connection.

  • Page 12: Pairing With Underfloor Heating Wiring Centre (Kl08Rf/Control Box)

    SALUS SmartHome Choose language by„ ” or „ ” Now thermostat is looking for the Go to SALUS Smart Home app buttons. Confirm by button. signal from the coordinator... Open main menu. Select „Settings”. Now enter to the „Setup Equipment”.
  • Page 13 Thermostat is connected. Go to the Select your thermostat and press Name your thermostat and go Smart Home app to configure it. „Connect equipment” button. „Next”... Select your KL08RF/Control Box added Press gear icon. Now choose „UFH Wiring Centre before. or Control Box”...
  • Page 14 Pin thermostat to the main app screen Choose „No” if you want to set Select the zone which you want attribute to and complete set up. your own schedule later or „Yes” if your thermostat. default now. Remember that you can pair one thermostat with more than one zone! Gateway stop flashing and turn to steady After that thermostat will display...

  • Page 15: Pairing With Wireless Trv Radiator Head

    SALUS SmartHome Choose language by„ ” or „ ” Now thermostat is looking for the Go to SALUS Smart Home app buttons. Confirm by button. signal from the coordinator... Open main menu. Select „Settings”. Now enter to the „Setup Equipment”.
  • Page 16 Select your thermostat and press Name your thermostat and go Press gear icon. „Connect equipment” button. „Next”... Choose „No” if you want to set Select your TRV radiator Now choose Smart Radiator Control. your own schedule later or „Yes” if head from the list.

  • Page 17: Pairing With Smart Plug Spe600

    SALUS SmartHome Choose language by„ ” or „ ” Now thermostat is looking for the Go to SALUS Smart Home app buttons. Confirm by button. signal from the coordinator... Open main menu. Select „Settings”. Now enter to the „Setup Equipment”.
  • Page 18 Select your thermostat and press Name your thermostat and go Press gear icon. „Next”... „Connect equipment” button. Choose „No” if you want to set Select your Smart Plug from the list. Now choose Smart Plug. your own schedule later or „Yes” if default now.

  • Page 19: Pairing With Smart Relay Sr600

    SALUS SmartHome Choose language by„ ” or „ ” Now thermostat is looking for the Go to SALUS Smart Home app buttons. Confirm by button. signal from the coordinator... Open main menu. Select „Settings”. Now enter to the „Setup Equipment”.
  • Page 20 Select your thermostat and press Name your thermostat and go Press gear icon. „Connect equipment” button. „Next”... Choose „No” if you want to set Select your Smart Relay from the list. Now choose Smart Relay. your own schedule later or „Yes” if default now.

  • Page 21: Pairing With Rx10Rf Receiver

    SALUS SmartHome Choose language by„ ” or „ ” Now thermostat is looking for the Go to SALUS Smart Home app buttons. Confirm by button. signal from the coordinator... Open main menu. Select „Settings”. Now enter to the „Setup Equipment”.
  • Page 22 Select your thermostat and press Name your thermostat and go Press gear icon. „Connect equipment” button. „Next”... Now choose Boiler Receiver. If RX10RF is set as Choose „No” if you want to set Choose „More” to expand the menu. „RX1” then choose option „Boiler Receiver”. If as a your own schedule later or „Yes”...

  • Page 23: Operating In Online Mode (By App)

    6.1 General Informations This section will show how to use your SQ610RF Quantum thermostat with the UGE600 Universal Gateway and the Salus Smart Home App. In order to do that, you will need a Salus UG600/UGE600 Universal Gateway, the Salus Smart Home App and Internet connection.

  • Page 24: Change Thermostat Name (Pencil Icon)

    6.3 Change thermostat name (pencil tool) Select the thermostat in Press the thermostat’s name. the main app menu. Click on the pencil icon. Name your termostat and confirm it by „Save” button.

  • Page 25: Setpoint Temperature Change

    6.4 Setpoint temperature change You can change the setpoint by sliding the cursor to left/right on your App. On your App screen, the setpoint temperature is the number displayed in a larger font. Select the thermostat in Old setpoint value. the main app menu.

  • Page 26: Heat/Cool Mode Change (Kl08Rf Connection)

    6.5 Heat/Cool mode change (KL08RF connection) SQ610RF Quantum thermostat could be a heating device or cooling device. Default thermostat is set for heating. To set cool mode you have to insert the jumper into „CO” terminal. Look at the instructions below: HEATING MODE: When there is no jumper at „CO”...

  • Page 27: Thermostat Modes

    6.6 Thermostat modes 6.6.1 Schedule Mode To activate Schedule Mode: Select thermostat in the Click on the work mode icon. main app menu. When schedule mode is Choose „Follow Schedule” on, then calendar icon will work mode. display. The SQ610RF Quantum Thermostat gives you the possibility to set schedules for the thermostat. You can add up to 6 programs during one day, by selecting the program's start time and temperature.
  • Page 28 TO SET THE SCHEDULE IN THE APP: Select thermostat in the Scroll down and press pencil button. Press thermostat’s name. main app menu. As you can see there is default schedule. You can delete all default intervals by button. Choose for which days you want to program your After days period selection use Then add a start time and schedule.
  • Page 29 After you’ve added all the intervals, ADDITIONALLY: You can Select thermostat for which you press „Save” to save it. Your schedule duplicate the same schedule for want to duplicate the schedule. has been saved and set. other thermostat’s. Click on the „Duplicate schedule”...
  • Page 30 TO SET DEFAULT SCHEDULE: Select thermostat in the Press thermostat’s name. main app menu. To set default schedule use „Default schedule” Scroll down and press pencil icon. button. It will remove all current intervals and it will set default schedule.

  • Page 31: Temporary Override Mode

    6.6.2 Temporary override mode Temporary override mode means manual temperature change during active schedule mode: Use slider to set new setpoint When you have overwritten the temperature When you overwrote temperature then temperature. then hand icon next will appear to calendar on the display you will see calendar which means that temporary override mode is with hand icon.

  • Page 32: Standby Mode

    6.6.4 Standby Mode In Standby mode the thermostat is displaying actual room temperature and maintain „Standby” setpoint temperature specified in thermostat settings (please refer to chapter 8.3). When thermostat works in Standby mode then you have no possibilities to change temperature setpoint. To activate.

  • Page 33: Key Lock Function

    6.7 Key Lock Function You can lock/unlock buttons in your thermostat by application. If buttons are locked/unlocked then also Press thermostat’s name. Click on the „padlock” icon to you can see it on thermostat display lock/unlock thermostat buttons. („padlock” icon will display). When thermostat is locked you can unlock it from app or from the device side (please refer to chapter 4.2).

  • Page 34: Compatibility With Window/Door Sensor Os600 / Sw600

    6.8 Compatibility with window/door sensor OS600 / SW600 SQ610RF Quantum thermostat paired with window/door sensor OS600/SW600 allows to create OneTouch rules when window/door is opened or closed. If thermostat will receive information from window/door sensor (that window has been opened for example) then OneTouch rule you programmed will turn off heating until window close.

  • Page 35: Compatibility With Smart Plug Spe600

    SPE600 Smart Plug to the SALUS SmartHome system (please refer to the SPE600 manual instruction). To pair SPE600 Smart Plug with SQ610RF Quantum thermostat please follow steps below: Select the thermostat in Press thermostat’s name.

  • Page 36: Compatibility With Smart Relay Sr600

    SR600 Smart Relay to the SALUS SmartHome system (please refer to the SR600 manual instruction). To pair SR600 Smart Relay with SQ610RF Quantum thermostat please follow steps below: Select the thermostat in Press thermostat’s name.

  • Page 37: Identification Mode

    6.11 Identification mode Identification mode can be useful when we are pairing more than one device in one moment and we don’t know which device is which. Beyond, if our system include more that one UGE600 Universal Gateway then we can easily identify which device is paired with which gateway.

  • Page 38: Pinning/Unpinning Thermostat To/From Application Dashboard

    6.12 Pinning/unpinning thermostat to/from application dashboard To pin/unpin thermostat from dashboard in Smart Home application please follow steps below: Open main menu in the app. Select equipment. Select All equipment option. Select your SQ610RF thermostat. Press on the „Pin” icon to pin/unpin thermostat to/from the app dashboard.

  • Page 39: User Settings (Basic Settings)

    6.13 User settings (basic settings) User settings of SQ610RF Quantum thermostat determine basic thermostat work modes (eg. thermostat calibration or standby temperature setpoint). Please consider that service parameters change should be done by experienced users. Select the thermostat in Press thermostat’s name. Select thermostat’s settings.

  • Page 40: Admin Settings (Installer Parameters)

    6.14 Admin Settings (Installer parameters) PLEASE NOTE: Admin settings are mainly for qualified installers or knowledgeable users. Select the thermostat in Press thermostat’s name. the main app menu. Scroll down to enter Select thermostat’s settings. „Admin settings”. Please Note: All service parameters with detailed admin settings are described on page 61!

  • Page 41: Onetouch Rules (Add/Edit)

    6.15 OneTouch rules (add/edit) OneTouch - function that distinguish SALUS Smart Home system in terms of functionality. OneTouch rules are pre-configured set of actions defined in the interface easy in use. You can switch it on or off anytime. OneTouch informs thermostat or other device how it has to work according to pre-set settings.
  • Page 42 You can also create your own OneTouch rule. As an example we will create OneTouch rule which activates „send me a notification” action under „temperature is below 10 °C” condition. Please look at the steps below how to set this OneTouch rule. Open main menu in the app.
  • Page 43 Select which thermostat you want to Choose the condition details for Enter a temperature setpoint trigger link up with your OneTouch rule. your thermostat. In this case select for your OneTouch rule. Press „Set” „Temperature Below” option. button to confirm. To finish OneTouch rule creation Select „DO THIS”...
  • Page 44 As an option OneTouch rule tile can Newly created OneTouch rule tile can be ... and on your dashboard. be pinned to the dashboard. found under OneTouch main menu... To force OneTouch rule activation ...and press it’s button. OneTouch rule is now activated. In this select it tile...

  • Page 45: Error Codes (Exclamation Mark In App)

    Error codes (exclamation mark in app) 6.16 If there is any error in the Smart Home system which relates to the devices performance or functionality then the Smart Home app will inform user about it by a red exclamation mark in the upper menu. Please look at the example below: Press the exclamation mark button.

  • Page 46: Wireless Signal Strength Test

    PLEASE NOTE: Every Smart Home system device which is powered 230VAC is also working as a signal repeater of ZigBee network. If system is based on battery devices there could be a need to use repeaters like Salus RE600, Salus RE10RF or any other device of Salus Smart Home series which is powered by 230V AC.

  • Page 47: Factory Reset (Removing Thermostat From The App And Zigbee Network)

    6.18 Factory reset (removing thermostat from the app and ZigBee network) To make thermostat factory reset and remove it from the ZigBee network please follow steps below: Select the thermostat in Press thermostat’s name. the main app menu. At the very bottom of Press „Delete”...
  • Page 48 You can also do factory reset from the thermostat directly. It will also remove your thermostat from the Zigbee network but you still will be able to see thermostat’s tile. After factory reset thermostat tile will change to dark grey colour. Press button to enter the Go to the Admin Settings.

  • Page 49: Installation In Offline Mode Without Salus Smarthome Application

    Please note! If your system has been installed in the OFFLINE mode using the UGE600 Universal Gateway and then connected to the Internet, all devices should be found in the SALUS Smart Home application (using „Scan for equipment” button). All devices found in the application don’t need to be reconfigured, because all settings are automatically copied from the gateway.

  • Page 50: Pairing With Underfloor Heating Wiring Centre (Kl08Rf/Control Box)

    7.2 Pairing with underfloor heating wiring centre (KL08RF/Control Box) PLEASE NOTE! For easier installation, please make sure you have already added underfloor heating wiring centre (KL08RF/Control Box) to your ZigBee network (please refer to the underfloor heating wiring centre manual instruction). 5 sec.

  • Page 51: Pairing With Wireless Trv Radiator Head

    7.3 Pairing with wireless TRV radiator head PLEASE NOTE! For easier installation, please make sure you have already added wireless TRV radiator heads to your ZigBee network (please refer to the wireless TRV radiator head manual instruction). 5 sec. 5 sec. Now thermostat is looking for the Select your language using Open the ZigBee network...

  • Page 52: Pairing With Rx10Rf Receiver

    7.4 Pairing with RX10RF receiver PLEASE NOTE! For easier installation, please make sure you have already added RX10RF receiver to your ZigBee network (please refer to the RX10RF receiver manual instruction). 5 sec. 5 sec. Select your language by Now thermostat is looking for the Open the ZigBee network buttons and confirm by button.

  • Page 53: Operating In Offline Mode

    8. OPERATING in OFFLINE MODE: 8.1 Setpoint temperature change (manual mode) SQ610RF Quantum thermostat is in manual mode by default. To change setpoint temperature please look at the steps below. buttons to set Confirm by button. Thermostat will go back to the temperature.

  • Page 54: Schedule Mode

    8.2 Schedule mode To program schedule in offline mode please follow steps below: Press button to enter the Enter into the schedule settings. main menu. There are 3 possible schedule variants. Use buttons to select schedule variant and confirm by button: Seven separate schedules for Separate schedule for WORKING DAYS...

  • Page 55: Temporary Override Mode

    8.3 Temporary override mode When thermostat is running schedule mode we can temporarily override it by setting new setpoint temperature. Calendar with hand icon means that buttons to Confirm by button. schedule has been overwritten until next change setpoint temperature. schedule program.

  • Page 56: User Settings (Basic Settings)

    8.6 User settings (basic settings) In OFFLINE mode user has got acces to the all thermostat settings. To open MAIN MENU press button on the main screen. 8.6.1 Time/Date Time/date change or edit can be done only in Offline mode. In Online Mode thermostat will synchronise current time and date based on information taken from the Internet.

  • Page 57: Holiday Mode

    8.6.2 Holiday mode Holiday mode is a special program temperature setpoint which thermostat will maintain for specified days. How to set HOLIDAY MODE: Press button to enter the Go to the user settings. Choose holiday mode option. main menu. Select „Yes” to SET ON the Using buttons set Set temperature setpoint for holiday...

  • Page 58: Thermostat Calibration

    8.6.3 Thermostat calibration Thermostat calibration is a function which allows user to recalibrate internal thermostat’s temperature sensor by a given number of degrees (in the range from -3,5 °C to 3,5 °C). To calibrate thermostat’s temperature sensor please follow steps below: Press button to enter the Go to the user settings.

  • Page 59: Display Floor Temp

    8.6.5 Display floor temp Display floor temperature is a function which is available only when thermostat works with external floor temperature sensor. To show/hide floor temperature value please follow steps below: Press button to enter the Go to the user settings. Choose display floor temp option.

  • Page 60: Heat/Cool Selection

    8.6.7 Heat/cool selection SQ610RF thermostat can work in heating or cooling mode. To set thermostat operating mode please follow steps below: NOTE: Available only if thermostat is paired with Smart Plug SPE600 or Smart Relay SR600 in ONLINE MODE. Press button to enter the Go to the user settings.

  • Page 61: Admin Settings (Installer Parameters)

    9. Admin settings (installer parameters) To enter admin settings (installer parameters) please follow steps below. Please refer to parameters table description before any changes. buttons to move up or down between all parameters. Every change/selection confirm by button: Press button to enter the Move buttons to When you will find Admin settings...
  • Page 62 Parameter name Parameter Values Description Default Values this algorithm is that the heating process begins with the TRV heads opening and ensures the flow in the system before the boiler starts. The system also turns off the boiler via the RX10RF (RX1) module before all TRV heads are closed.
  • Page 63 Parameter name Parameter Values Description Default Values When S1/S2 contacts are opened, thermostat activates standby mode ONE TOUCH - this option is available only in ONLINE mode. In this scenario S1/S2 input is used to work with volt-free contact. By closing/opening S1/S2 contacts we can trigger any OneTouch rule created in the Smart Home application.
  • Page 64 - PIN CODE will be used to completely lock thermostat. PIN CODE can be set from the Smart Home application or from device side. In case of any problems with thermostat unlocking, please contact the SALUS-Controls Technical Department. DEVICE INFORMATION PAIRED WITH...

  • Page 65: Factory Reset

    • Reinstall the TRV head or replace it. If necessary, contact with the TRV paired with thermostat - TRV hardware error. HARDWARE SALUS Technical Department. PROBLEM • Set the heating medium temperature or change floor sensor MAX/ FLOOR Floor is overheated (heating mode).
  • Page 66 ERROR DISPLAY ERROR DESCRIPTION TROUBLESHOOTING CODE DESCRIPTION • If LED diode of the Network Status is flashing, pair the wiring centre with the system in accordance to the manual instruction and pair thermostat with wiring centre. • Check TRV head batteries. CONNECTIVITY Thermostat lost contact with the TRV LOST TRV...
  • Page 67 • Reinstall the TRV head or replace it. If necessary, contact with the TRV GEAR TRV head has a problem with the DEFECT internal gear mechanism. SALUS Technical Department. • Check assembly of the TRV head on radiator valve insert and reinstall TRV FAILED Adaptation error of the TRV head ADAPTATION assembled on the radiator valve the TRV head.

  • Page 68: Cleaning And Maintenance

    86 x 86 x 11 mm 14. Warranty SALUS Controls warrants that this product will be free from any defect in materials or workmanship, and shall perform in accordance with its specification, for a period of five years from the date of installation. SALUS...
