Level The Print Jet Nozzle

Verify the Print Jet Nozzle Level

Leveling the print jet nozzles is very important to ensure quality prints especially after

replacing a print jet, an extruder assembly or the print pad.

The Print Jet Level Gap calibration ﬁle requires all cartridge bays to be loaded with the

same material type cartridges.

NOTE: Ensure the ﬁle used matches the printer model and the installed print

material type. All installed cartridges must be of the same material type.

(Ex. If the cartridge bays have ABS material cartridges installed, print the

ABS Level Gap calibration ﬁle.)

These ﬁles are available at www.3dsystems.com/shop/cubepro/downloads. The Level Gap

Calibration ﬁles are available from the Calibration Files download link in the

Files

section of the web page.

The ﬁle names are listed below:

PLA:

noz12_PLA_LEVELGap.cubepro (This ﬁle is for printing PLA on a CubePro Duo)

noz123_PLA_LEVELGap.cubepro (This ﬁle is for printing PLA on a CubePro Trio)

ABS:

noz12_ABS_LEVELGap.cubepro (This ﬁle is for printing ABS on a CubePro Duo)

noz123_PLA_LEVELGap.cubepro (This ﬁle is for printing ABS on a CubePro Trio)

Nylon:

noz12_NYL_LEVELGap.cubepro (This ﬁle is for printing nylon on a CubePro Duo)

noz123_NYL_LEVELGap.cubepro (This ﬁle is for printing nylon on a CubePro Trio)

Other ﬁles may be made available in the future.

The following illustration demonstrates what you would see when the print jet nozzles are

properly leveled.
