3D Systems CubePro Manual page 12

SHOCK WARNING: EXERCISE CAUTION WHENEVER YOU ARE NEAR
ELECTRICAL COMPONENTS.
WARNING: BEFORE SERVICING THESE COMPONENTS, ENSURE YOU ARE
WEARING A WELL-GROUNDED ELECTRO-STATIC DISCHARGE (ESD)
STRAP. ESD PROTECTION IS REQUIRED.
WARNING: NEVER PULL ON WIRES TO DISCONNECT THE CONNECTORS.
THIS COULD DAMAGE THE WIRES AND THE CONNECTORS AND VOID THE
MANUFACTURER'S WARRANTY.
The following procedure is intended to provide instructions about how to level print jets for
printers with more than 1 print jet.
1. For printers with two (2) or three (3) print jets, loosen the T10 torx screws on
extruders 1 and 3.
CAUTION: There should be enough access to reach the torx screws using an
insulated torx driver. Exercise caution when working around the PCBs.
NOTE: Print jet 2 should not need adjustments.
2. Connect the printer to utility power, turn on the main power switch and then turn on
the display.
3. Navigate to the Print Plate Calibration screen and select MOVE JETS.
