13.
Verify the wiper blade meets the tapered portion (A) of the print jet nozzle. If it does,
the jet wiper is properly adjusted. Proceed to step 16.
NOTE: If the wiper tip is too high, proceed to the next step. If the wiper tip is
too low, proceed to step 15.
14.
If the wiper blade is too high, remove the jet wiper assembly and turn the adjustment
thumbscrew (A) clockwise. Reinstall the jet wiper and return to step 13.
15.
If the wiper tip is too low, remove the jet wiper assembly and turn the adjustment
thumbscrew (A) counter-clockwise. Reinstall the jet wiper and return to step 13.
