EN
IntroductIon
This HDMI Extender includes a transmitter unit and a receiver unit, allows HDMI signal to be
transmitted up to 50 meters at 4Kx2K@30Hz and up to 30 meters at 4Kx2K@60Hz long away via
a single CAT6/6A/7 cable in a point-to-point configuration. It supports IR pass back with a wide
IR frequency 20-60 KHz. Transmitter with a HDMI loop out, convenient for monitor at location. It
supports receiver be powered from the transmitter (connect power supply to the transmitter only),
please note that this HDMI Extender can not use with switch or router. It is perfect for application of
outdoor advertising, video clips, monitor system, home entertainment and conference, etc.
FEaturEs
1. Metal casing, stable and durable
2. Transmission over single CAT6/6A/7
3. Transmitter support one HDMI loop-out
4. Highest resolution up to 4Kx2K@60Hz
5. Support HDMI2.0, compatible with HDCP2.2
6. Built in EDID pass back function to get better compatibility
7. Support IR pass back function (IR range support 20~60KHz)
8. Support distance up to 50 meters when 4K@30Hz and 30 meters when 4K@60Hz
9. Can be powered by network cable. It only needs to connect the 12V power on the transmitter unit,
both transmitter and receiver start work.
PacKagE contEnts
• Transmitter unit x1 pc
• Receiver unit x 1 pc
• Power supply DC12V/1A x 1pc
• User's manual x 1pc
• IR blaster extension cable x 1pc
• IR receiver extension cable x 1pc
InstaLLatIon rEQuIrEMEnts
1. HDMI source device (computer graphics card, DVD,PS3, HD monitoring equipment etc).
2. HDMI display device like SDTV, HDTV, and projector with HDMI port.
3. UTP/STP Cat.6/6A/7 network cables, which following the standard of EIA-568B.
10
