4. Switching

4.1 Switching at the device

EPC NET 24x disposes of two buttons: "select" and "ok". By
pushing "select", the LED of Power Port 1 starts blinking which
means that it is selected. By pushing the button again, the next
Power Port is selected. If you want to change the switching
state of the selected Power Port, push the "ok" button for two
seconds.
Figure 11 Buttons
You can check the status of the Power Ports by the color of the
Power Port status LED (green=enabled/red=disabled).

4.2 Switching by Webinterface

Go to the website of EPC NET 24x. Enter the IP address of EPC
NET 24x into the address line of your internet browser:
http://IP address of EPC NET 24x/
Figure 12 Login
