4.3 Fuses

You can see the status of the fuses by the colour of the fuse
LEDs Fuse 1, Fuse 2, Fuse 3).
Green = enabled
Red = disabled
While using the webinterface you can see the states of the
fuses, too. It is listed in the Control Panel.
Figure 15 Fuses
If one, or more than one of the fuses is shown as disabled,
check the fuses, the connections and the connected de-
vices.
Each fuse secures 8 Power Ports for a power of 16A.
Fuse 1: Power Port 1-8
Fuse 2: Power Port 9-16
Fuse 3: Power Port 17-24
If there is one fuse disabled, it can easily be enabled again.
Simply press it back into the case of EPC NET 24x.
Expert Power Control NET 24x 17
