Chapter 1 Overview

DC Power Connector

Figure 1-6
1
2

1552 Antenna Ports

Figure 1-7
Access Point DC Power Connector and Ground Lug (All Models)
12 VDC non-hazardous locations input port
(PG 13.5 thread size)
Bracket mounting hole (M8x1.25 x 12mm dp) 4
shows the antenna port locations for model AIR-CAP1552H-x-K9.
2 3
1 4
3 Bracket mounting hole (M8x1.25 x 12mm dp)
Ground lug location (connection for earth
grounding (minimum VD 16 mm, 6 awg)
(M4x.7 .30 THD Depth)
Cisco Aironet 1552 Series for Hazardous Locations Installation Guide
Hardware Features
1-11
