Access Point Power Injector
Caution: Power injector (AIR-PWRINJ1500-2=) is not certified for installation within hazardous
Caution
locations environments.
Figure 4-3
1
1
Mounting tabs
2
AP POWER LED
3
FAULT LED
Cisco Aironet 1552 Series for Hazardous Locations Installation Guide
4-88
Power Injector Connectors and LEDs
4
AC POWER LED
5
TO AP—Ethernet connector (RJ-45) to access point
(10/100/1000BASE-T)
6
TO SWITCH—Ethernet connector (RJ-45) to switch
(10/100/1000BASE-T)
2
3
4
5
Chapter 4
Troubleshooting
6
1
