Chapter 4 Troubleshooting
Figure 4-2
1
Note
Set up a terminal emulator program on your PC to communicate with the access point. Use the following
Step 2
settings for the terminal emulator connection: 9600 baud, 8 data bits, no parity, 1 stop bit, and no flow
control.
When finished, remove your serial cable, and close the hinged cover (see the
Step 3
Point Hinged Cover" section on page 3-58

Access Point Power Injector

The power injector (AIR-PWRINJ1500-2=) has three LEDs on the front end of the case (see
For detailed information on the power injector, see the Cisco Aironet 1550 Series Outdoor Mesh Access
Point Power Injector Installation Instructions.
Console Port Location on Access Point Models (AIR-CAP1552SA/SD-x-K9 Shown)
1
Console port
Not used for 1552WU. The
Note
1552WU console is only available
by opening the device and
connecting to the internal console
port.
The Cisco part number for the DB-9 to RJ-45 serial cable is AIR-CONCAB1200. To order a
serial cable, browse to:
http://www.cisco.com/pcgi-bin/marketplace/welcome.pl
2
2 Not used
for instructions).
Cisco Aironet 1552 Series for Hazardous Locations Installation Guide

Access Point Power Injector

"Working with the Access
Figure 4-3).
