Overview

1 Overview
1.1

Features

Three 5 V power supply options: power jack, ST-LINK connector or daughterboard
Boot from user Flash, system memory or SRAM
Speaker
1 Gbyte MicroSD Card
16 Mbyte serial Flash
2
I C/SMBus compatible serial interface temperature sensor
Two RS-232 communication channels with support for RTS/CTS handshake on one
channel
IrDA transceiver
Induction motor control connector
JTAG and SWD debug support
240x320 TFT color LCD
Joystick with 4-direction control and selector
Reset, wakeup, tamper and user push buttons
Four LEDs
RTC with backup battery
Extension connector for daughterboard or wrapping board
Embedded ST-LINK
IDD current measurement circuit
HDMI CEC
1.2

Demonstration software

Demonstration software is preloaded in the board's Flash memory for easy demonstration of
the device peripherals in stand-alone mode. For more information and to download the
latest version available, please refer to the STM32100B-EVAL demonstration software
available on www.st.com.
1.3

Order code

To order the STM32F100VBT6 evaluation board, use the order code STM32100B-EVAL.
