2.2. Specifications

Wetted Materials..................................
Operating Temperature.......................... -4°F to 257°F (-20°C to 125°C)
Maximum Pressure............................... 300 psi @ 212°F (2,068 Pa @ 100°C)
Maximum Flow Rate.............................. 10 ft/sec (3 m/sec)
Measuring Range................................. 0 to 5000 μS/cm
Resolution........................................... 4.5 significant digits
Standard Sensor Cable Length................ 10 ft (3 m)
Cable Wire Colors................................. White Wire
Maximum Transmission Distance............. 3,000 ft (914 m)
The sensor will arrive with a protective cap. Remove when in process or calibrating.
Replace the cap on the sensor when placed in storage.
Make sure all wetted materials are compatible with process chemicals at operating temperatures
and pressures.
Thermo Scientific AquaSensors
Sensor Body – CPVC, PEEK or 316 Stainless Steel
Electrodes - Titanium
O-Ring Seals - Viton®
(Consult factory for customized material construction)
Black Wire
Red Wire
Green Wire (Reference Electrode)
Yellow Wire (Temperature/RTD)
Drain/Shield (Earth)
™ ™
AnalogPlus Contacting Conductivity Sensor User Guide
(-5V)
(Ground)
(Active Electrode)
