3.2.3. Immersion Mounting
For immersion mounting applications the sensor is connected to a 1 inch to 1.5 inch reducing coupling.
A 1.5 inch extension pipe is added to protect the cable from damage.
Figure 3.9: Immersion mounting assembly
™
™
Thermo Scientific AquaSensors
AnalogPlus
Contacting Conductivity Sensor User Guide
14
