2. PRODUCT DESCRIPTION

2.1. Sensor Description

The Thermo Scientific AquaSensors 1.0 inch Contacting Conductivity sensor is available in different cell
constants to accurately measure your continuous industrial application. The wires in the sensor cable are
color coded to allow for quick and easy installation into the Model C99 controller.
Thermo Scientific AquaSensors
The wires in the sensor cable are color coded to match the
terminal strip connection within the Model C99 Controller.
The sensor body has 1 inch NPT threads for the following
mounting options:
Standard 1 inch NPT pipe tee insertion.
Thermo Scientific AquaSensors immersion mounting
assembly.
Thermo Scientific AquaSensors pipe adapter for union
™ ™
AnalogPlus Contacting Conductivity Sensor User Guide
Figure 2.2: Conductivity sensor hook-up
6
