4.16.6 GRAPHICS

A monochrome graphic has three factors as listed in the table.
Key Factors
Video Mode
Pixel State
Shape State
Illustrative examples are given below.
Shape State
SHAPE_FILL
SHAPE_NORMAL
Parameters
VIDEO_REVERSE
VIDEO_NORMAL
DOT_MARK
DOT_CLEAR
DOT_REVERSE
SHAPE_FILL
SHAPE_NORMAL
Pixel State
DOT_MARK
Functions
1 See SetVideoMode()
0
1 See circle(), line(), putpixel() and rectangle()
0
-1
1 See circle(), rectangle()
0
DOT_CLEAR
