■ Ordinary Testing Procedure
Preparations
・Is the AIR SUPPLY(Test Pressure) being supplied?
・Is the A.P SUP (Pilot Valve Operation Pressure) being supplied?
・Is the work bowl valve opened?
・Is the work connected to the work port?
・Are each of the setting values correct?
1. Press the START key．(Testing starts)
(If using a Remote, input the START signal from the REMOTE connector.)
2. The test result will be output when the testing is concluded.
Judgment
Result
(＊1) For operations 1~10, once the settings are set, there is no need to repeat that process for each test.
When setting values are changed, the first test will always be a mandatory fitting testing.
（＊2）If you choose fitting set 0, 1 or 2, and then alter a setting item which
influences the measurement conditions, the first measurement (The 1
measurement) will be a mandatory fitting measurement. The setting items
which influence measurement conditions are: Charge 1, Charge 2, Balance 1, Balance 2,
Detect, F Detect, Lead P., Test P., and Fitting Set.
BASIC OPERATIONS SETTING PROCEDURES
－0000Pa
－
0
Detect GroupNo 00
OK
1.000
Exhaust GroupNo 00
Manual
＋
ml/m
time
st
Test Value
