Fukuda FL-601 Series Operational Manual page 102

■ Optional Equipment APU (Pneumatic Regulator)
○ Summary :
By using an optional APU unit (pneumatic regulator), a stable test pressure (charge) can be obtained in a
shortened time.
Use a dedicated APU unit (type number X005) with the FL-601.
See page 13 for details.
○ Installation directions：
APU－70W □-□-X005
APU－90W □-□-X005
110(90)
92(80)
4‐φ6(5)
○ APU Control Cable Wiring
ＭＲ－８ＬＭ
1
Rear panel terminal
2
3
Connection
Applied Connector
Pin Number
Applied Connector
(Included)
Applied Cable
Wiring Precautions
An APU connecting cable (length 1.5 m) is included with the purchase of the APU-□-X005 SERIES．
Figure in ( ) is only for use with 70W
Height170（164） ㎜
6
4
7
5
8
Tester Side
(APU SIGNAL)
MR-8LM
1
3
5(Shield Line)
6
7
MR-8LM (Tester Side)
RO3-PB8F (APU Side)
At least 0.3 SQ, with a shield. Twisted pair cable
1. Use pin numbers 1 and 6 to pair joint wires.
2. Shield joint wire pin number 5
3. Make sure that the length of the cable is as short as possible.
(Cable length within 5m)
OPTIONAL EQUIPMENT APU UNIT
APU－130W □-□-X005
165
145
4‐φ7
Shield Line
APU Side
(IN PUT)
RO3-PB8F
D
―
B
―
Ｅ(Shield Line)
―
F
―
E
―
Height 220 ㎜
A Ｇ
B Ｈ F
C
Ｒ０３－ＰＢ８Ｆ
Ｄ E
Rear panel terminal
Remarks
+15V
Analog Input
GND
－15V
GND
101
