Fukuda FL-601 Series Operational Manual page 53

BASIC OPERATION
Setting
ITEM
Display
Page
Decimal
Digit
point
setting
Lead
Lead.P
Pressure
Setting
Test.P
Pressure
Setting
4/5
Fitting
Fitting
setting
set
switch
Set fixed
RevData
correction.
Data
Out
5/5 Output
Data
Mode
Switch
52
SETTING CONTENTS
CONTENTS
Set the decimal point for the leak value or the +NG
judgment value indicated on the display
Sets the lead supply pressure for the TURBO test time.
If the pressure is±10% over the set pressure following
the Charge 1 Process, a P.NG judgment will be
conducted.
Judgment will not occur if the test value is set to "0".
Sets the supplied test pressure. If the pressure is±10％
Test
over the set pressure following the Charge 2 Process, a
P.NG judgment will be conducted. Judgment will not
occur if the test value is set to "0".
Sets the test setting.
Set
Conduct fitting test, calculate and save c
0 constant, perform fitting calculation in the
next normal test by fixing c constant.
Conduct fitting calculation by fixing c and
1
b constants.
Conduct fitting calculation by fixing c, b
2
and a constants.
During the detection process, calculate the
Use "0" for ordinary testing.
data's regression line and obtain the test
result using its slope.
3
Fitting key becomes disabled and the test
is
measurement (DetectTime).
Calculate the c, b and a constants for each
test. Perform the same calculation both
4 during the fitting test and the normal test.
The only difference is the setting detection
time (F DetectTime, DetectTime).
Normally use set "0"
Set the fixed correction value which is deducted from the
measured value
value
Selects the output data contents from the RS-232C.
Mode
0
1
2
3
4
Select Mode 4 when using a printer.
The following data will be output as the process
data.
CHG1：CHG2：BAL1
BAL2：DET：.FDET
Contents
performed only using
.
Output Contents
Test
Process Data
Result
× ×
○ ×
DET Process
○
(.F.DET Process)
CHG1Process
CHG2ProcessB
BAL1Process
○
BAL2Process
DET Process
(MDET Process)
○ ×
Work Internal
Pressure
Differential
Pressure
TESTING RANGE
.0000, 0.000, 00.00, 000.0
0000.
V
L
M
UL
H1
V
L
M
UL
H1
0 ～ 4
normal
±.0000～±9999.
BCC
×
○
○
○
×
0 ～ -90.0 kPa
0 ～ 99.9 kPa
0～700kPa
0～20kPa
0 ～ 20MPa
0 ～ -90.0 kPa
0 ～ 99.9 kPa
0～700kPa
0～20kPa
0 ～ 20MPa
0~4
