Fukuda FL-601 Series Operational Manual page 52

■ SETTING CONTENTS
The FL-601 has the following setting items:
Setting
ITEM
Display
Page
Delay Process
Delay
Charge 1
Charge1
Process Time
1/5
Charge 2
Charge2
Process Time
Balance 1
Balance1
Process Time
Balance 2
Balance2
Process Time
Detection
Detect
Process Time
Exhaust
Process Time
F Detect Detection
Process Time
2/5
Work Volume
W. Volume
M. Volume
+NG +NG Setting
+2NG +2NG Setting
3/5
-NG -NG Setting
F+NG F+NG Setting
F-NG F-NG Setting
The Work Volume setting is used when changing the leak differential pressure（Pa/min）detected by the tester
to the leak rate（ml/min）.
WARNING
Be aware that when an incorrect value is input, testing will be conducted with that value.
CONTENTS
Sets the delay time from when testing is first
initiated until actual pressurization begins.
Time
Sets the lead pressure pressurizing time for
TURBO. If it is set to "0" , the TURBO function does
not operate. It is necessary to use an external
pressure conversion valve (ESV3) when using the
TURBO function.
Sets the test pressure charging time.
Sets the time for stabilizing the air in both the work
and the internal master after the pressure is cut
off.
Sets the time for stabilizing the internal pressure of
the air for both the work and the master.
Sets the duration
of
the leak detection
process.
Exhaust Sets the amount of time given to exhaust the air
within the work parts.
Fitting
Sets the amount of time used to detect the air
during the Fitting test. (This is invalid when
FittingSet is set to 3).
Sets the internal volume of the work to be tested.
The work's internal volume to be input includes the
tester and test piping internal volume.
(The FL-601Tester Internal Volume is4.31ml)
You may also input the value of the work volume for
testing operation and maintenance operation.
Tests the internal volume of the Master. Please
refer to P 57 for more information.
Master
Volume
Sets the +NG judgment setting value.
Evaluated as +NG when the set value and test
value are the same.
Sets a failure value other than the +NG judgment
value.
For example, +NG can be used for small leaks and
+2NG for large leaks. It is evaluated as +2NG when
the set value and test value are the same.
Sets the –NG judgment setting value.
Evaluated as -NG when the set value and test value
are the same.
Sets the +NG judgment setting value during the
fitting test.
Evaluated as F+NG when the set value and test
value are the same.
Sets the -NG judgment setting value during the
fitting test.
Evaluated as F-NG when the set value and test
value are the same.
BASIC OPERATION
If Fitting Set is 4
If Fitting Set is 3 and Unit
Change is Pa
SETTING CONTENTS
TESTING RANGE
0.0 ～ 999.9 sec
0.0 ～ 999.9 sec
0.5 ～ 999.9 sec
0.5 ～ 999.9 sec
0.5 ～ 999.9 sec
5 ～ 20.0 sec
0.5 ～ 999.9 sec
0.5 ～ 999.9 sec
5.0 ～ 200.0 sec
1.000E0
～
5.000E5
( 1ml～ 500L )
1.000E0
～
5.000E5
( 1ml～ 500L )
0001 ～ 9999 ml/min
Digit set designates the
decimal point location.
0001 ～ 9999 ml/min
Digit set designates the
decimal point location.
0001 ～ 9999 ml/min
Digit set designates the
decimal point location.
0001 ～ 9999 ml/min
Digit set designates the
decimal point location.
0001 ～ 9999 ml/min
Digit set designates the
decimal point location.
51
