4.2 Top

10...32 VDC
1 1
GND
2 2
Reset
3 3

4.3 User Profiles

The modem offers a choice of profiles:
Default factory setting:
The default factory settings enable you to achieve a fixed de-
fined basic state of the modem. Starting with this "basis",
you can customize the modem according to your require-
ments.
User profiles 0 and 1:
You can save configurations in the user profile, which may
be re-used for certain purposes.
A part of the S registry is saved in each profile. In the descrip-
tion, the affected registries are marked with an "*" in the S
registry.
June 06
1
2
INSYS MICROELECTRONICS GmbH
Internet: www.insys-tec.de
Sales: insys@insys-tec.de
Support: support@insys-tec.de
3
4
The modem is not "off hook" (it has
not "lifted the receiver" yet) and the
DCD line at the modem is perma-
nently switched on.
Terminal Meaning
10..32V DC Power supply 10V - 32V DC
GND Ground
Reset Reset input
