INSYS Modem 56k small INT 2.0/USB 1.0
3

Notes Regarding the Use of the Manual

This manual uses the symbol
notes will be marked accordingly.
All factory settings are marked "default".
Example (Chap. 5.7.3): Enter old password (default: QWERTY)
In Chapters 4 to 6 the description consists of two columns. Individual
functions are described on the left side. The according AT commands and
the modem responses can be found in the right column.
Function description
Example (Chap. 5.2.7):
After the hardware reset, load the user profile 1
All AT commands start with the letters AT and end with a "Return" (Car-
riage Return - CR). AT commands can be entered in capital or small let-
ters. The command is evaluated as soon as the modem received a re-
sponse.
In the following, the used syntax is explained:
ATDT
<Expression>
<Expression>
Expression
Examples:
ATDT<n>
ATDT1234
+
Connect
lished
>
June 06
AT+MS=<Modulation>, [Automode]
AT+MS=V92
AT+MS=V92,1
for especially important notes. Further
AT command (font: Courier, bold)
Input of a parameter (font: Courier, bold)
Input of an optional parameter
(Font: Courier, bold)
Response from the modem (font: italic)
Dialing of the phone number <n>
Dialing of the phone number 1234
The connection to the remote terminal is estab-
Input prompt during the remote configuration.
Notes Regarding the Use of the Manual
AT command
ATZ1
Selection of the modulation
type
Selection of the modulation
type V.92
Selection of the modulation
typeV.92 with automatic
adjustment
