Howdens TOWER UNIT 3 DRAWERS Assembly Instructions Manual page 5

1
Pull the sliding part of the
lower drawers out first and
hold in place.
1 - Pull the sliding part of the lower drawer runners out (F) and sit
the drawer on top. Whilst holding the runners in place, slide the
13
drawer back until the drawer clicks into place.
WALL MOUNTING
BRACKETS
We recommend you use
the Wall Mounting Brackets
provided to fix the Tower Unit to
a wall (where possible). This will
prevent the unit being pulled over.
Use suitable fixings.
Page 5 of 5
2
Drawer shown
Locking button
from underneath.
2 - Use the locking button to secure the drawer. Repeat for all
drawers. To remove a drawer, reverse the operation.
Fix the wall mounting bracket to both sides of the Tower Unit.
15
(Use suitable fixings when attaching to the wall).
Turn to
adjust height
14
Use two people to stand up right.
Use suitable
wall fixings
x2
UNB_TUDRAWER_INSTR_01.19
