Assembly - Howdens TOWER UNIT 3 DRAWERS Assembly Instructions Manual

Note: B panel shown
1
Lay panels (B&C) on a flat surface. Fit cams & dowels to both panels.
x2
3
Page 2 of 5
x10
4
x2
Fix through these holes highlighted
1 2 3
4
Insert the screws into the holes shown on both sides (B & C).
x10
x11
2
Place the cams in the holes. (Apply to all shelves).
x9
5
x2
x4
UNB_TUDRAWER_INSTR_01.19
