Making The Drawers - Howdens TOWER UNIT 3 DRAWERS Assembly Instructions Manual

9
Insert a drop of glue into all x6 holes in item A.
1
Drawer back
1 – Lay drawer side (I) on a flat surface, insert the base (K) into the
12
groove then hold the back panel (M) in place.
Page 4 of 5

Making the drawers

x6
x1
x6
10
10
(Repeat on all drawer sides).
Drawer side
x2
Drawer base
Drawer back
Drawer side
2 – Place the other drawer side (J) over the base and fasten the
back panel (M).
x4
x4
9
11
2
Drawer front
Drawer base
3 – Turn the drawer around and add the drawer front (L) .
9
(Repeat on all drawers).
x2
(Repeat on all drawer fronts).
3
UNB_TUDRAWER_INSTR_01.19
x4
