Command access MLRK1 Series Insert Instructions page 5

10. Re-install top pins on both activating brackets and slide on the push pad making sure pins are in the proper channel.
11. Re-install (2) screws securing the push pad
end caps on the front & back.
1
Select your preferred torque mode (ships in standard torque) Press the device push pad to the
Step 1-
desired setting. (Recommend to fully depress and release 5%, giving the device room for
changing door conditions.)
While depressing the push pad, apply power. (i.e. presenting the credential to the reader).
Step 2-
Continue to keep pad depressed, the device will beep 6 times. After the beeps have stopped,
Step 3-
release the pad and now the adjustment is complete. If not to your liking repeat the three
steps.
Once you found the correct location, flip the dip switches to off to lock programming.
Step 4-
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
12. Set the "Push to Set Adjustment" following the steps below,
remembering to turn the Programming Switch to the off position
when completed.
2
Setting PTS
MM4S SWITCHES
OFF
1 STANDARD TORQUE
ON
HIGH TORQUE
ON
2
PTS PROGRAMMING ON
OFF
PTS PROGRAMMING OFF
