Special function setting

■[F90] Setting of all functions
All functions can be set, one after the other.
<Operation>
Press the or button in function selection mode to display [F90].
Setting of all functions
or
Press the button to select all functions.
[oFF] (unused)
selected.
Press the button
to set.
Return to
function selection
mode.
1: Setting of functions
Every time the button is pressed, the function steps in the order of Function settings on page 43.
Set using the or
Refer to each section for the setting details.
.
Press the button.
After the change to [oFF] (unused),
press the
Return to function
selection mode.
[F90] Setting of all functions completed
buttons.
Move on to setting of all functions.
Setting of each function
button to set.
Measurement mode
-42-
[on] (used) selected.
 1
Press the
button for 2
seconds or longer.
No.PS※※-OMM0007-H
