Troubleshooting

○Troubleshooting
Applicable Pressure switch: ZSE40A(F)/ISE40A
If the cause of the failure cannot be identified and normal operation can be recovered by replacement with
a new the product, this indicates that the product itself is faulty. The product damage can be caused by the
operating environment (network construction, etc.), therefore contact SMC.
The pressure
switch does not
operate correctly
Yes
No
The switch output
is ON
The switch output
is OFF
The switch output
is chattering
Slow switch
output response
The indicator LED
operates incorrectly
Analogue output
Is not provided
(specified accuracy
is not satisfied)
An Error is
displayed
-53-
The indicator LED
is ON
The indicator LED
is OFF
The indicator LED
is ON
The indicator LED
is OFF
Refer to Fault
No.1
The product is
faulty
Refer to Fault
No.2
The product is
faulty
Refer to Fault
No.1
Refer to Fault
No.3
Refer to Fault
No.4
Refer to Fault
No.5
The product is
faulty
Refer to Fault
No.6
Refer to Fault
No.7
