■[F 0] Units selection function
Only the product with Units selection function can be set.
The displayed unit can be changed, and depends on the pressure range.
(kPa/MPa units are available when the product does not have the units selection function.)
<Operation>
Press the or button in function selection mode to display [F 0].
Select the Display Unit
Press the or
button to select the display unit.
Press the
Display unit and minimum setting unit
Unit ZSE40AF
MPa 0.001
kPa 0.1
2
kgf/cm 0.001
bar 0.001
psi 0.02
InHg 0.1
mmHg 1
Press the button.
button to set.
Setting of [F 0] Units selection function completed
ZSE40A ISE40A
0.001 0.001
0.1 1
0.001 0.01
0.001 0.01
0.01 0.1
0.1 -
1 -
-27-
Move on to select the display unit.
Return to function selection mode.
