Function Setting

■Function selection mode

In measurement mode, press the
function to be changed, [F
Press the button for 2 seconds or longer in function selection mode to return to measurement mode.
:
Some functions are not available depending on part number. All functions are displayed with [F
description. If a function is not available, the function is displayed as [---].

■Default setting

At the time of shipment, the following settings are provided.
If this condition is acceptable, then keep these settings.
To change setting, enter function selection mode.
[F 0] Units selection function
Symbol
Nil or M
P
[F 1] Setting of OUT1
Item
Output mode Select hysteresis mode window comparator mode or OFF mode.
Reversed output Select reversed output.
Pressure setting Set the ON or OFF value of the switch output.
Hysteresis Set the hysteresis to prevent chattering.
Display colour Select the display colour.
[F 2] Setting of OUT2
Same setting as for [F 1] OUT1.
At the output mode, the error detection mode can also be selected.
The display colour is linked to the setting of OUT1, and can not be set for OUT2.
button for 2 seconds or longer to display [F 0]. Select to display the
].
Page 27
Model Default setting
ISE40A MPa
ZSE40A(F) kPa
ISE40A
psi
ZSE40A(F)
Page 28
Description
Page 31
-25-
] followed by the function
Default setting
Hysteresis mode
Normal output
ISE40A: 0.500 MPa
ZSE40A: -50.7 kPa
ZSE40AF: 50.0 kPa
ISE40A: 0.050 MPa
ZSE40A: 5.1 kPa
ZSE40AF: 5.0 kPa
ON: Green
OFF: Red
No.PS※※-OMM0007-H
