○Specifications (products with M8 (3 pin) connector)
Model No.
Rated pressure range
Set pressure range
Withstand pressure
Minimum display unit
Applicable fluid
Power supply voltage
Current consumption
Switch output
Max. load current
Max. applied voltage
Residual voltage
Response time
Short circuit protection
Repeatability
Hysteresis mode
Hys
teresis
Window comparator mode
Display
Display accuracy
Indicator LED
Enclosure
Operating temperature range
Environ
Operating humidity range
ment
Withstand voltage
Insulation resistance
UL Temperature rating
Temperature characteristics
Standard
1: If the applied voltage fluctuates around the set value, the hysteresis must be set to more than the fluctuation width. Otherwise,
chattering will occur.
○Piping specifications
Model No.
Port size
Pressure sensing part
Material of
wetted parts
Piping port
Weight
ZSE40A
(vacuum)
0 to -101.3 kPa
10.0 to -105.0 kPa
500 kPa
0.1 kPa
Air, inert gases and incombustible gases
12 to 24 VDC ±10%, ripple (p-p) 10% or less (protected against reverse
NPN or PNP open collector 1 output
1 V or less (at 80 mA load current)
(with anti-chatter function: 20, 100, 500, 1000 or 2000 ms)
3 1/2digits, 7-segment, dual-colour display (red/green)
±2% F.S. ±1 digit (at ambient temperature 25±3 C)
LED is ON when output is ON OUT: Orange
Operation: -5 to 50 C, Storage: -10 to 60 C (no condensation or freezing)
Operation, Storage: 35 to 85% RH (no condensation)
1000 VAC, 1 minute between terminals and housing
50 M or more at 500 VDC between terminals and housing
Surrounding air temperature rating: Maximum 50
±2% F.S. (25 C reference)
CE, UL/CSA, RoHS
01
R1/8
(with M5 female thread)
C3602 (electroless nickel plating)
O-ring: HNBR
45 g
-63-
ISE40A
(positive pressure)
-0.100 to 1.000 MPa
-0.105 to 1.050 MPa
1.5 MPa
0.001 MPa
connection)
45 mA or less
80 mA
28 V (NPN output)
2.5 ms or less
Provided
±0.2%F.S. ±1 digit
1
0 to variable
IP65
N01
NPT1/8
(with M5 female thread)
Silicone
46 g
