INSTALLATION

FYI: It is not necessary to disconnect power to the CPU and monitor(s) before installation.

Monitor Connection

Disconnect the monitor cable at the CPU and reconnect it to the "MONITOR 1" port on the VOPEX. (See Fig. 1)
1.
(A second DVI-HDMI-x-MM cable may be required (sold separately)- one has been supplied for connection to the CPU.)
Plug a second monitor into the "MONITOR 2" port on the VOPEX.
2.

Mouse Connection

Disconnect the mouse at the CPU and reconnect it to one of the female USB type A 'USER 1 DEVICES" ports on the
1.
VOPEX.
Connect a second mouse (or optional USB extension cable NTI USB-A+A-5M) to the female USB type A "USER 2 DEVICES"
2.
ports on the VOPEX.

Keyboard Connection

1. Disconnect the keyboard at the CPU and reconnect the keyboard to the remaining female USB type A "USER 1 DEVICES"
port on the VOPEX.
2. Connect a second keyboard (or optional USB extension cable NTI USB-A+A-5M) to the remaining female USB type A "USER
2 DEVICES" ports on the VOPEX.

Figure 1- Connect User 1 Keyboard, Mouse, and Monitor
