- Page 1 ® VOPEX Series VOPEX-2/4KVIM-A VOPEX PS/2 KEYBOARD, MONITOR, and MOUSE SPLITTER Installation and Operation Manual MAN046 Rev Date 9/20/2016...
- Page 2 TRADEMARK VOPEX is a registered trademark of Network Technologies Inc in the U.S. and other countries. COPYRIGHT Copyright © 1998, 2016 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
- Page 3 TABLE OF CONTENTS INTRODUCTION................................1 MATERIALS..................................1 Materials Supplied with this kit ............................ 1 Optional Materials................................ 1 INSTALLATION ................................2 Connect the CPU................................. 2 Connect the Monitor(s) ..............................2 Connect the Mouse(Mice)............................2 Connect the Keyboard(s)............................. 2 Connect the AC adapter .............................. 2 SPECIAL MOUSE CONSIDERATIONS.........................
- Page 4 • Keyboards and mice are hot-pluggable • Interconnect NTI switches and splitters for complex applications • Supports 1920 x 1200 resolution at 150MHz bandwidth Option: VOPEX wtih stereo audio support- connect an audio source and up to 4 self-powered-stereo audio speakers-...
- Page 5 NTI VOPEX PS/2 KVM SPLITTER INSTALLATION Turn OFF power to the CPU that will be connected to the VOPEX before connecting or disconnecting any cables. WARNING If power to the CPU is not turned OFF before connecting or disconnecting cables, damage to the CPU may result.
- Page 6 NTI VOPEX PS/2 KVM SPLITTER SPECIAL MOUSE CONSIDERATIONS NOTE If the VOPEX is power-cycled with the CPU ON, the mouse driver must be reloaded for mice to function properly. Hot plugging limitations Any mouse to be emulated must be connected to "MOUSE1" at VOPEX power-up. e.g. If at a later time the user wants to hot-plug 3-button mice, a 3-button mouse must have been connected to "MOUSE1"...
- Page 7 NTI VOPEX PS/2 KVM SPLITTER MODES OF OPERATION This VOPEX has three basic modes of operation: INSTANT AUTO. DELAYED AUTO, and USERx. Press the “MODE” button on the front panel of the VOPEX to select the desired mode per the chart below:...
- Page 8 NTI VOPEX PS/2 KVM SPLITTER AUDIO SUPPORT (Optional) The VOPEX can be ordered with optional 3.5mm stereo audio ports (ex. VOPEX-4KVIMA-A) for connection to an audio source (“Audio In”) and up to 4 self-powered stereo speakers (Audio 1-4). Audio support provides the following additional features: •...
