VOPEX-3GSDI-4
3G-SDI Splitter: 4-Port
Installation and Operation Manual
MAN420
Rev 3/21/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VOPEX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NTI VOPEX Series

Summary of Contents for NTI VOPEX Series

  • Page 1 ® ® VOPEX-3GSDI-4 3G-SDI Splitter: 4-Port Installation and Operation Manual MAN420 Rev 3/21/22...
  • Page 2 TRADEMARK VOPEX and the NTI logo are registered trademarks of Network Technologies Inc in the U.S. and other countries. All other brand names and trademarks or registered trademarks are the property of their respective owners. COPYRIGHT Copyright © 2022 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.

  • Page 3: Materials Supplied

    SDI-compliant displays or video processors. Materials Supplied VOPEX-3GSDI-4 4K HDMI Splitter 100-240VAC, 50/60Hz ; 5VDC 3A (PS4297) AC Adapter Contact an NTI product consultant for 9VDC or 12VDC power supply options Country-specific line cord URL Slip with path to this manual...
  • Page 4 LABEL CONNECTOR/LED DESCRIPTION Button to power the unit ON/OFF ON/OFF Red LED illuminates to indicate proper power to the unit POWER Red LED illuminates to indicate SDI signal is connected to the LOCK INPUT BNC Female for connection of SDI video source INPUT Connector BNC Female...

  • Page 5: Installation

    Installation 1. Connect the SD/HD/3G-SDI video source to "SDI INPUT" using 75 Ohm RG6 BNC cable. 2. Connect up to four SD/HD/3G-SDI displays to the "SDI x OUTPUT" ports (where x is 1-4) using 75 Ohm RG6 BNC cables. 3. Connect the power supply and power up the VOPEX, video source and displays (in any order).

  • Page 6: Specifications

    Specifications Resolution HDTV resolutions to 1080p @ 60Hz Video Input Connector One female BNC connector for SD/HD/3G-SDI video source Video Output Connectors Four female BNC connectors for SD/HD/3G-SDI displays. Video bandwidth o 3G-SDI: 2.97 Gbps o HD-SDI: 1.485 Gbps o SD-SDI: 270 Mbps Impedance 75 Ohm Protocols supported...
