Wallbox ePark
F

Closing

C l o s e t h e C h a r g e P o i n t a s p e r t h e f o l l o w i n g s t e p s o f v e r i f i c a t i o n a n d o p e r a t i o n .
1 — P O W E R I N P U T
Before proceeding, make sure voltage is present in the terminal blocks.
For Three-Phase models pay special attention to Neutral Cable.
2 — C A R E F U L W I T H T H E W I R E S
Before closing the unit, keep in mind that all cables should remain inside.
3 — C H E C K T H E P L U G S
Plugs should be in good condition before starting the unit.
4 — E L E C T R I C A L P R O T E C T I O N S
If the unit includes electrical protections, rearm all of them.
5 — C L O S I N G
Place the sealing washers on the screws and then place both in the Charge Point to close it. Do
not thight the screws yet.
6 — C H E C K T H E B E AC O N L I G H T S
All beacon lights should light properly. Here's the reference:
7 — O P E R AT I O N
Check that no abnormal noise appears while the unit is charging.
Installation guide
P L U G S TAT E B E AC O N C O LO R
A v a i l a b l e
C h a r g i n g
Fa u l t
G r e e n
B l u e
R e d
