CyberData SIP Paging Adapter Connecting page 4

Bogen PCM2000 Zone Paging System with old PCMTIM to SIP Paging Adapter
The IP Endpoint Company
Bogen PCM2000 Application Configuration
PCM
TIM
S1
S2
TEL
S3
INT
S4
SEL
S5
S6
S7
0 1
POWER
TONE
VOLUME
BGM SRC
VOLUME
NIGHT
RING
TEL
LINE
OVER
RIDE
Notes
Before connecting your CyberData product, power off PCM2000 system. Set the dip switch settings
per the above diagram (S1 and S7 to the right)
IN
BGM
SRC
RT
Do not connect the PCMPS2 power supply to the PCMCPU until the module switch settings and
NC
wiring connections have been completed
RLY
COM
ONE
NO When using a Bogen ZPM Module for single analog Page ALL scenario, enable Send pre‐configured
NC
DTMF for Analog Zone on the Paging Adapter's Device tab then use the Zone field to place the
RLY
COM
analog zone number. Click Save and Reboot for the change to take effect. End result ‐> dial Paging
TWO
Adapter's extension then the device will automatically choose your single Page ALL zone.
NO
GND ST
When using a Bogen ZPM Module for analog multi‐zone scenario, enable Manual DTMF Entry for
Analog Zone on the Paging Adapter's Device tab. Click Save and Reboot for the change to take effect.
End result ‐> dial Paging Adapter's extension, a menu will prompt for the analog zone number fol‐
lowed by #.
S1
S2
Power off PCM system to set dip switches
S3 TEL
INT
1 and 7 to the right and 2 through 6 to the left
S4
SEL
S5
S6
S7
0 1
TEL LINE
6 - Not used
5 - Contact Closure
4 - Dry audio (T)
3 - Dry audio (R)
2 - Contact Closure
1 - Not used
930671D
Connections—VOX Configuration
SIP Paging Adapter Connections
+ -
s
Page Port Output Connections
Pin Description
1 Fault Sense Input (Common).
2 Fault Sense Input (Sense).
3 Positive 600-Ohm Audio Output
4 Negative 600-Ohm Audio Output
5 Audio Ground Reference.
6 Relay Contact - Common
7 Relay Contact - Normally Open
a.The 600-Ohm audio output of the page port is
also suited for interfaces with lower input
impedances.
b.1 Amp at 30 VDC for continuous loads.
+
-
a
a
b
b
