Peavey MMA 8150T Amplifier to Singlewire Paging Adapter Connections
The IP Endpoint Company
Peavey MMA 8150T Amplifier
Singlewire Paging Adapter Connections
+ -
+
-
PGM IN
or
Notes
CyberData SIP Paging Adapter's RCA line level output can connect to either an AUX 2 module
or a TPM-S2 Module.
This page shows the possible connections to an AUX 2 module.
Connect the SIP Paging Adapter's Line Out to one of the RCA phono input jacks.
930887A
Advertisement
Table of Contents
Related Manuals for CyberData Singlewire Paging Adapter
Summary of Contents for CyberData Singlewire Paging Adapter
- Page 1 Singlewire Paging Adapter Connections PGM IN Notes CyberData SIP Paging Adapter's RCA line level output can connect to either an AUX 2 module or a TPM-S2 Module. This page shows the possible connections to an AUX 2 module. Connect the SIP Paging Adapter's Line Out to one of the RCA phono input jacks.
- Page 2 Peavey MMA 8150T Amplifier to Singlewire Paging Adapter Connections The IP Endpoint Company Peavey MMA 8150T Amplifier Singlewire Paging Adapter Connections PGM IN Balanced Shield/Drain Wire Keep as short as possible Shield/Drain Wire Page Port Connections Pin Description Fault Sense Input (Common).
