NTI ENVIROMUX Series Wiring Instruction Manual page 4

Example of possible sensor configuration settings for
Tamper connection at Digital Input
4
If you remove the default
checkmark from Auto
acknowledge, then even if
someone tries to override the
keypad control over the strike,
the strike will not deactivate
until the alert is acknowledged
by the administrator.
You will need to Disable the
Relay Interlock (under
Administration-System- Other
Options) in order to associate
the same output relay with two
sensors.
Otherwise, you can wire to
have a second output relay
break the circuit when the
keypad tamper switch closes.
