- Page 1 ® ENVIROMUX Series Temperature/Humidity Sensor Installation Manual ENVIROMUX-STSM-E7, STHSM-E7 Temperature/Humidity sensors ENVIROMUX-STHS-LCD Temperature/Humidity sensors ENVIROMUX-STHSB ENVIROMUX-STHS-N4085IND Temperature/Humidity Sensor Temperature/Humidity sensor MAN215 Rev Date 1/19/2016...
-
Page 2: Table Of Contents
NTI ENVIROMUX TEMPERATURE/HUMIDITY SENSOR ATTACHMENT TABLE OF CONTENTS Introduction..................................1 Mounting..................................1 Connect Sensors................................3 RJ45 Sensors ................................3 ENVIROMUX-STHS-PRCIND100-Pxx ........................4 ENVIROMUX-STHS-LCD............................5 RJ45 Sensor Cable..............................7 TABLE OF FIGURES Figure 1- Keyhole slot for standard mounting ............................ 1 Figure 2- Mounting bracket for outdoor installation.......................... -
Page 3: Introduction
NTI ENVIROMUX TEMPERATURE/HUMIDITY SENSOR ATTACHMENT INTRODUCTION Many different sensors can be connected to the ENVIROMUX Series Enterprise Environment Monitoring Systems. Series models covered by this manual include ENVIROMUX-SEMS-16U and ENVIROMUX-16D/5D/2D. A complete listing of available sensors and accessories can be found at http://www.networktechinc.com/enviro-rems.html... -
Page 4: Figure 3- Din Rail Clip
NTI ENVIROMUX TEMPERATURE/HUMIDITY SENSOR ATTACHMENT If you have purchased an ENVIROMUX Sensor with a DIN rail clip for DIN rail mounting, see the drawing below for instructions to install the sensor to the DIN rail. DIN rail Clip ears for gripping... -
Page 5: Connect Sensors
The various temperature and humidity sensor models offered by NTI have varying ranges of performance capabilities, as indicated in the table on page 6. Be sure to match the sensor installed to the operating range of the environment it will be expected to work in. Using a sensor outside of its intended temperature range may result in damage to the sensor. -
Page 6: Enviromux-Sths-Prcind100-Pxx
NTI ENVIROMUX TEMPERATURE/HUMIDITY SENSOR ATTACHMENT ENVIROMUX-STHS-PRCIND100-Pxx The ENVIROMUX-STHS-PRCIND100-Pxx is a precision wide-range extreme environment sensor that includes a probe-type temperature sensor attached to the aluminum case with a special extreme-environment cable. The cable length is defined by the “xx” in the “Pxx”. -
Page 7: Enviromux-Sths-Lcd
NTI ENVIROMUX TEMPERATURE/HUMIDITY SENSOR ATTACHMENT ENVIROMUX-xD firmware version 2.31 or later is required to support this sensor. ENVIROMUX-STHS-LCD The ENVIROMUX-STHS-LCD is a temperature/humidity sensor with built-in LCD display. It has a temperature range of -4 to 140°F (-20 to 60°C) ±0.7°F (±0.4°C) and will sense 0 to 90% relative humidity ±4% RH (30°C). -
Page 8: Sensor Calibration
All temperature/humidity combination sensors and humidity-only sensors are factory-calibrated and are not designed to be calibrated in the field. In the event recalibration of your sensor is desired, please contact NTI for an RMA to return your sensor. Sensors within warranty will be recalibrated at no charge. Normal labor charges will apply to sensors out of warranty. -
Page 9: Rj45 Sensor Cable
NTI ENVIROMUX TEMPERATURE/HUMIDITY SENSOR ATTACHMENT RJ45 Sensor Cable The CAT5 connection cable between the ENVIROMUX and connected external sensors is terminated with RJ45 connectors and must be wired according to the EIA/TIA 568 B industry standard. Wiring is as per the table and drawing below.
