5 Mounting and connection

5 Mounting and connection
MiniCODER
► Ensure the measuring surface does not come into contact with other objects.
► Only touch connector pins and wires if you are suitably earthed, for example
using an ESD wrist strap, to prevent damage to the electronic components
due to electrostatic discharge.
► Only remove the MiniCODER from the foam packaging immediately prior to
mounting.
Target wheel
► Check the target wheel for damage to the teeth and contamination. Replace
a damaged target wheel.
Measuring system
► Check the module of the MiniCODER and target wheel match.
► After mounting the MiniCODER ensure the air gap between the measuring
surface and measuring scale is within the range allowed to ensure correct
function.
