1 About these instructions
1.5

Conventions

1.5.1

Symbols, marks, notes

The following symbols, marks and notes are used in these instructions:
Notes on preventing damage
Note about components susceptible to ESD
Information for understanding or optimising work processes
► Work step to be undertaken
→ page 40
Page reference to a different part of these operating instructions
1.5.2

Abbreviations and glossary

ESD
EMC
Air gap
Measuring
scale
Target wheel
MiniCODER
40
Conventions
Electro-Static Discharge
Electromagnetic compatibility
Distance between the measuring surface on the MiniCODER
and the outside diameter of the target wheel
General term for target wheel, toothed rack or slotted disc
These instructions primarily cover target wheel applications.
Similar information then applies to other measuring scales.
Tooth wheel for measuring tasks, general term: Measuring
scale
Protected name for Lenord + Bauer sensors in the product
family GEL 24xx
Lenord + Bauer
GEL 2444
