SIM5218E Hardware Design

4.2 Module RF output power

Table 32: SIM5218E conducted RF output power
Frequency
GSM850 33dBm ±2db
E-GSM900 33dBm ±2db
DCS1800 30dBm ±2db
PCS1900 30dBm ±2db
GSM850(8-PSK) 27dBm ±3db
E-GSM900(8-PSK) 27dBm ±3db
DCS1800(8-PSK) 26dBm ±3db
PCS1900(8-PSK) 26dBm ±3db
WCDMA 2100 24dBm+1/-3db
WCDMA 1900 24dBm+1/-3db
WCDMA 900 24dBm+1/-3db

4.3 Module RF receive sensitivity

Table 33: SIM5218E conducted RF receive sensitivity
Frequency Receive sensitivity
GSM850 < -106dBm
E-GSM900 < -106dBm
DCS1800 < -106dBm
PCS1900 < -106dBm
WCDMA 2100 < -108dBm
WCDMA 1900 < -108dBm
WCDMA 850 < -106dBm

4.4 Module operating frequencies

Table 34: SIM5218E operating frequencies
Frequency
GSM850
E-GSM900
DCS1800
PCS1900
WCDMA 2100
WCDMA1900
WCDMA 900
SIM5218E_HD_V1.03
Max Min
5dBm±5db
5dBm±5db
0dBm±5db
0dBm±5db
5dBm±5db
5dBm±5db
0dBm±5db
0dBm±5db
<-50dBm
<-50dBm
<-50dBm
Receive
869 ～ 894MHz
925 ～ 960MHz
1805 ～ 1880MHz
1930 ～ 1990MHz
2110 ～ 2170MHz
1930 ～ 1990MHz
925 ～ 960MHz
55
Transmit
824 ～ 849MHz
880 ～ 915MHz
1710 ～ 1785MHz
1850 ～ 1910MHz
1920 ～ 1980MHz
1850 ～ 1910MHz
880 ～ 915 MHz
11.06.2009
