SIM5218E Hardware Design
21 CAM_CLK
22 CAM_STANDBY
23 SPK_P
24 SPK_N
25 EAR_P
26 EAR_N
27 HPR
28 HPL
29 RESET
30 GPIO2
31 GPIO3
32 GPIO4
33 GPIO5
34 SD_CLK
35 SD_CMD
UART_RXD has been pulled down with a 15kR resistor to ground in module.
Note:
USIM DATA has been pulled up with a 22kR resistor to V_USIM in module.
IIC_SDA and IIC_SCL have been pulled up with two 2.2kR resistors to 2.6V in module.
So there is no need to pull them up or down in your application circuit.
SIM5218E_HD_V1.03
NC 50
NC 49
NC 48
NC 47
NC 46
NC 45
NC 44
NC 43
NC 42
NC 41
NC 40
NC 39
NC 38
NC 37
NC 36
65
CAM_VSYNC NC
CAM_PCLK NC
CAM_RESET NC
IIC_SDA NC(See Note)
IIC_SCL NC(See Note)
POWER_ON NC
0.1u
MIC_N ground
0.1u
MIC_P ground
HP_MICP NC
HKADC NC
VREG_AUX NC
SD_DATA3 NC
SD_DATA2 NC
SD_DATA1 NC
SD_DATA0 NC
11.06.2009
cap to
cap to
