Radio Characteristics

4.9.1

Module RF Output Power

The following table shows the module conducted output power, it is followed by the 3GPP TS 05.05 technical
specification requirement.
Table 22: SIM900B GSM 900 and GSM 850 conducted RF output power
PCL Nominal output power (dBm)
0-2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19-31
SIM900B_Hardware Design_V2.01
±5KV
±5KV
±2KV
±5KV
±2KV
±2KV
GSM 900 and EGSM 850
39
37
35
33
31
29
27
25
23
21
19
17
15
13
11
9
7
5
Tolerance (dB) for conditions
Normal
±2
±3
±3
±3
±3
±3
±3
±3
±3
±3
±3
±3
±3
±3
±5
±5
±5
±5
37
Smart Machine Smart Decision
±10KV
±10KV
±8KV
±10KV
±5KV
±8KV
Extreme
±2.5
±4
±4
±4
±4
±4
±4
±4
±4
±4
±4
±4
±4
±4
±6
±6
±6
±6
