SIM5218E Hardware Design
SMS
SIM interface
External antenna
Audio features
Serial interface
Phonebook management
SIM Application Toolkit
Real time clock
Timer function
Physical characteristics
Firmware upgrade
GPS
PCM
Table 4：Coding schemes and maximum net data rates over air interface
Coding scheme
CS-1:
CS-2:
CS-3:
CS-4:
MCS-1
MCS-2
MCS-3-
MCS-4
MCS-5
MCS-6
MCS-7
MCS-8
MCS-9
SIM5218E_HD_V1.03
Supports TFC selection limitation on the UL factoring in the
transmissions on the HS-DPCCH as required in TS 25.133.
MT, MO, CB, Text and PDU mode
SMS storage: SIM card
Support transmission of SMS alternatively over CSD or GPRS. User
can choose preferred mode.
Support SIM card: 1.8V ,3V
Connected via 50 Ohm antenna connector or antenna pad
Speech codec modes:
Half Rate (ETS 06.20)
Full Rate (ETS 06.10)
Enhanced Full Rate (ETS 06.50 / 06.60 / 06.80)
AMR(WCDMA)
AMR+QCP(GSM)
A5/1, A5/2, and A5/3 ciphering
Serial Port 4-line or 2-line mode on Serial Port Interface
Serial Port can be used to control module by sending AT command or
receiving the GPS NMEA data.
Support phonebook types: SM, FD, LD, RC, ON, MC.
Support SAT class 3, GSM 11.14 Release 98
Support USAT
Implemented
Programmable vian at command
Size: (58.7±0.1)mm ×(28.77±0.1)mm ×(4.5±0.2) mm
Weight: 15g
Firmware upgrade over USB interface
Support GPS by NMEA port on USB interface or UART. Supports A-GPS
and S-GPS.
Multiplex on GPIOs.
1 Timeslot
9.05kbps
13.4kbps
15.6kbps
21.4kbps
8.80kbps
11.2kbps
14.8kbps
17.6kbps
22.4kbps
29.6kbps
44.8kbps
54.4kbps
59.2kbps
12
2 Timeslot
18.1kbps
26.8kbps
31.2kbps
42.8kbps
17.60kbps
22.4kbps
29.6kbps
35.2kbps
44.8kbps
59.2kbps
89.6kbps
108.8kbps
118.4kbps
4 Timeslot
36.2kbps
53.6kbps
62.4kbps
85.6kbps
35.20kbps
44.8kbps
59.2kbps
70.4kbps
89.6kbps
118.4kbps
179.2kbps
217.6kbps
236.8kbps
