SimCom SIM5218E Hardware Design page 12

SIM5218E Hardware Design
GPRS/EDGE
connectivity
Temperature range
DATA GPRS:
CSD:
DATA EDGE
DATA
UMTS/HSDPA/HSUPA
SIM5218E_HD_V1.03
●Class 3 (+24dBm +1.7/-3.7dB) for WCDMA 1900, WCDMA FDD BDII
●Class 3 (+24dBm +1.7/-3.7dB) for WCDMA 900, WCDMA FDD BDVIII
GPRS/EDGE multi-slot is up to class 12
GPRS mobile station class B
Operating Temperature: -30°C to +80°C
Storage temperature -40°C to +85°C
GPRS data downlink transfer: max. 85.6 kbps
GPRS data uplink transfer: max. 42.8 kbps
Coding scheme: CS-1, CS-2, CS-3 and CS-4
SIM5218E supports the protocols PAP (Password Authentication
Protocol) usually used for PPP connections.
The SIM5218E integrates the TCP/IP protocol.
Support Packet Switched Broadcast Control Channel (PBCCH)
CSD transmission rates: 2.4, 4.8, 9.6, 14.4 kbps, non-transparent
Unstructured Supplementary Services Data (USSD) support
EDGE E2 power class for 8 PSK
DTM (simple class A), multi-slot class 12
Downlink coding schemes – MCS 1-9
Uplink coding schemes – MCS 1-9
BEP reporting and test mode B
8-bit, 11-bit RACH
PBCCH support
phase/2 phase access procedures
Supports E-DCH (E-DPDCH, E-DPCCH) and E-AGCH,E-RGCH,
E-HICH
Supports HS-DSCH (HS-SCCH, HS-PDSCH and HS-DPCCH)
Supports a maximum of four simultaneous HS-SCCH channels
Supports a maximum of 10 HS-PDSCH channels
Supports both QPSK and 16 QAM modulation.
Supports CQI, and ACK/NACK on HS-DPCCH channel
Supports all incremental redundancy versions for HARQ
Can switch between HS-PDSCH and DPCH channel resources as
directed by the network.
Can be configured to support any of the two power classes 3 or 4
Supports network activation of compressed mode by SF/2 or HLS on
the DPCH for conducting inter-frequency or inter-RAT measurements
when the HS-DSCH is active.
STTD on both associated DPCH and HS-DSCH is supported
simultaneously.
CLTD mode 1 is supported on the DPCH when the HS-PDSCH is
active.
STTD on HS-SCCH is supported when either STTD or CLTD Mode 1
are configured on the associated DPCH.
11
11.06.2009
