KEYS LOCKED OUT
9.2.3 Detection Faults
Fault
CASE TAMPER
Code Guessing
9.2.4 Power Supply Problems
Fault
BATTERY FAULT
xxx
BAT LOAD FAIL
BAT CRITICAL
MAINS FAIL xxx
LOW VOLTS xxx
9.2.5 Engineer Indications
Fault
Engineer Access
Denied
Check Failed Input
xxx
Error input Areas
not accessible
Error some Areas
cannot be
disarmed
9.2.6 Wireless Faults
Fault
U-01 (xx)
WLs LOW BATT
I-01 (xx)
WLs LOW BATT
B-01 (xx)
WLs LOW BATT
a) More than one device connected
at the same address.
b) Too many incorrect key presses
have been entered to creating 'Code
Guessing' condition.
Description
Case tamper switch open
Up to 13 Invalid key presses have
been entered or 3 invalid tags have
been presented.
Description
Battery not present or Battery volts
low
Battery Load Test has failed
Battery being disconnected
Mains supply failed
Power supply volts low
Description
Access to Engineer menu NOT
possible, as system is not fully
disarmed.
Input in fault on attempting to exit
Engineer mode.
An input has been programmed to
an area for which no arming point is
valid to disarm.
Arming points have been
programmed so it's possible to arm
an area, but not disarm it.
Description
Low battery on wireless keyfob
(user) number 'xx'
Low battery on wireless input
number 'xx'
Low battery on wireless bell number
'xx'
a) Correct addressing so that there are no
overlaps. Then power the system down and
back up again to correctly reinitialise.
b) Wait 90 seconds for the keypad to be re-
introduced onto the system.
Solution
Ensure the switch is closed
Press the x key to clear.
Solution
Note: This indication should be expected
during recharge -after a mains failure.
Only displays if option selected. Battery
uncharged or capacity below specification –
then it may need replacing.
Protects the battery from deep discharge
damage during extended mains failure.
Note: The system is about to be powered
down!
System detects that the mains frequency is
out of specification, as well as voltage. Note:
'AC FAIL' timer operative
Battery volts below normal 'battery fault'
level during a mains failure
Solution
Ensure that ALL areas are disarmed, using
suitable user codes / tags at the appropriate
keypads / readers.
Applies to 24-hour tamper, or other input
types that would generate an alarm condition
if the system were returned to disarmed
mode. This also applies to tamper faults on
other input types. Check for the fault on
input, or omit it in programming.
It would therefore be impossible to fully
disarm the system after a tamper alarm on
that input. Programming must be adjusted
before exiting Engineer mode.
Programming must be adjusted before
exiting Engineer mode.
Solution
Replace the battery on the keyfob mentioned
Replace the battery on the input device
mentioned
Replace the battery on the radio bell
mentioned
