Pyronix Enforcer 32-WE Programming Reference Manual page 14

0011 Arm Fail
0012 Entry Deviation
0013 System Ready Any
0014 Bell Any
0016 Strobe Any
0017 Bypass Rearm Any
0018 Burglary
(Unconfirmed) Any
0019 Ready All
0020 Exit Starts All
0021 Exit Starts Any
0022 Final Arm Any
0023 Strobe if Arm Fail
0024 Unable to Arm
0025 Keyswitch Disarm
0026 Arm with Bypass
0027 Pulsed Burglary
Any
0028 Power Fault
0031 Entry
0032 Exit
0033 Entry / Exit
0034 Lights
0035 Follow Input
0036 Shunt Fault
0037 Restore 1
0038 Restore 2
0039 PIR Latch 1
0040 PIR Latch 2
0041 AC Mains Good
Pre-set time after start of exit time, if exit
procedure is not complete
When deviation from entry route occurs,
during entry time
When any of the inputs but the Entry
Delay and Follow are closed
After alarm in any area
After alarm in any area
When inputs are bypassed at rearm in any
area
At Burglary alarm in any area
When all inputs but the 'Entry Delay' and
'Follow' inputs are closed
At start of exit time to arm LAST area
When exit time starts to arm FIRST area
When ANY area has been armed
Works similar to output 016, but also fires if the 'arm fail' timer expires.
This output turns on for 5 seconds when the system is disarmed via a keyswitch
input (either pulsed or latched keyswitch)*
Output activates when an arming procedure is completed with inputs bypassed.
Active when the system is armed with an input bypassed.
Active when burglary alarm is triggered, but deactivates once the Pulsed
Intruder timer has expired (see Program Timers).
Active during low volts and battery faults. Restores at code entry after fault
cleared.
Active during any Entry time
Active during any Exit time
Active during any entry or exit time
When exit or entry timer starts
Active when a specific input number has been activated. It allows the following
options to be programmed:
- Follow Type (Follow, Timed, Latched, Code Reset);
- Follow What (Input, Shunt List, Sub-Area, Area);
- Follow When (Always, When Armed, When Disarmed);
- Input to Follow (between 1 to 64)
This input activates if someone tries to shunt an input group where some of the
inputs allocated to this group are open.
At code entry to arm. The normal state of
this input is 0v and it changes to 12v
when activated.
Activates whenever an additional area is
armed. The normal state of this input is
0v and it changes to 12v when activated.
When armed (and in Walk Test)
This is the inverse polarity to
PIR Latch 1
Output showing the 230v mains supply is present
Page: 14
At code entry to rearm
At code entry to disarm
If fault exists, and after final arm
When alarm silenced or when siren
timer expires
When disarmed or when strobe
timer expires
When system disarmed
At code entry to silence
If fault exists, and after final arm
At disarm FIRST area (i.e. no longer
fully armed)
At code entry to disarm LAST area
At code entry to disarm LAST area
20 seconds after arm/disarm
procedure completed
After 3 seconds
When disarmed
At alarm, or when disarmed
At alarm, or when disarmed
