Intracom netMod User Manual page 88

User's Manual of netMod Network Termination Unit
Malfunction
You have a device that
supports the CLIP service
connected to the analogue
port, but the service does not
work.
You get overcharged when
you are connected to the
Internet Service Provider.
Possible Cause
Your device does not
recognise the CLIP
information.
Incompatibility on the
negotiation process
between the ISP
equipment and the
netMod, when using
the second
B-channel.
86
Correcting Action
• Be sure that the CLIP
service has been activated
by the operator.
• Be sure that your device is
working with FSK signalling.
• Raise the level of transmitted
signal using the command
AT/CLIPLEVEL=10.
• If you are not a ML-PPP
subscriber at 128Kbps, be
sure that you have not the
ML-PPP service activated on
netMod. At the selection of
Extra Settings, give the
command b40.
• Ask from the operator to
activate the AOC-D service
and then check the charge
metering using the AT
Commands
ats89=4 and
atch?
