Intracom netMod User Manual page 71

0 0
1
1 0
2
2 0
4
5 0
32
6 0
64
S90= 0 –
63
S91= 0 -
255
S100= bit dec
0 0*
1
1 0
1
S101= bit dec
0 0*
1
S102= 1
S103= Bit
0-1
2
3
4
5
6
7
S108+n= dec
1
2
0 *
S118= Bit dec
0 Disable Total and Last call's charging counters of analogue adapter,
ab1.
1 Enable Total and Last call's charging counters of analogue adapter,
ab1.
0 Disable Total and Last call's charging counters of analogue adapter,
ab2.
2 Enable Total and Last call's charging counters of analogue adapter,
ab2.
0 Disable Total and Last call's charging counters of data port.
4 Enable Total and Last call's charging counters of data port.
0 Disable the metering pulse of analogue adapter, ab1.
32 Enable the metering pulse of analogue adapter, ab1.
0 Disable the metering pulse of analogue adapter, ab2.
40 Enable the metering pulse of analogue adapter, ab2.
0-3F Set TEI (Terminal Endpoint Identifier)
0 - Set LCN (Logical Channel Number)
FF
hex Supplementary Services Protocol
0* Functional Protocol is enabled.
1 Keypad Protocol is enabled.
0 3.1 Khz Audio Bearer capability
1 Speech Bearer capability
hex CID transmission method
0* CID FSK pattern is transmitted during ringing between the 1
ring.
1 CID FSK pattern is transmitted prior to ringing.
1 Enable BAP (Bandwidth Allocation Protocol) for PPP links
Bin
0 Do not wait for restart
01 Wait for 1 second
10 Wait for 5 seconds
11 Wait for 20 seconds
1 PAD connection, makes a X.28 PAD call when is set. That means to
send a X.29 PAD protocol ID (01000000) as call user data in the call
request packet.
Selects PAD initial profile
0 Default profile is simple X.28 profile.
1 Default profile is transparent X.28 profile.
Configure the X.25 link to be a PVC
Sends a restart request when Layer 2 is up.
When is set you can use a PAD interface, instead of an AT interface.
0 Default (no semi – permanent connection)
1 Set it if your connection type is semi permanent
hex n=0 for analogue adapter ab2, n=1 for analogue adapter ab1
1 High Layer Telephony
2 High Layer Compatibility with Fax G2/G3
0 No High-Layer-Compatibility information element will be sent
hex Bit mapped register
69
