User's Manual of netMod Network Termination Unit
4.

Calling Line Identification Restriction (CLIR)

Using AT Commands write on the S85-Register the proper value to activate / deactivate
this service on the analogue ports ab1 and ab2 of netMod.
ATS85=0 deactivates the service on both analogue ports ab1 and ab2 (your number will
appear on the device of the called subscriber).
ATS85=1 activates the service on the ab1 port and deactivates the service on the ab2
port. Your number will not appear on the device of the called subscriber when calling from
the ab1 port.
ATS85=2 deactivates the service on the ab1 port and activates the service on the ab2
port. Your number will not appear on the device of the called subscriber when calling from
the ab2 port.
ATS85=3 activates the service on both analogue ports ab1 and ab2 of netMod (your
number will not appear on the device of the called subscriber).
Note that the S85-Register is also used for the COLR service.
5.

Connected Line Restriction (COLR)

ATS85=0 deactivates the service on both analogue ports ab1 and ab2.
ATS85=4 activates the service on the analogue port ab1 and deactivates the service on
the analogue port ab2.
ATS85=8 deactivates the service on the analogue port ab1 and activates the service on
the analogue port ab2.
ATS85=12 activates the service on both analogue ports ab1 and ab2.
It must be noticed that the S85-Register is also used for the CLIR service.
76
